Automatic Case Packer Packaging Machine For Edible Oil PET Bottle Tin Can
The main drive adopts variable frequency speed regulation and PLC control technology, combined with human-machine interface, to achieve stepless speed regulation. The main control adopts a German SIEMENS programmable controller. This machine is equipped with special pneumatic components in conjunction with a grabbing head to achieve the grabbing and releasing of products. Through mechanical operation, pneumatic and electrical control, the product is accurately loaded into the carton from the bottle conveyor, ensuring smooth operation.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Technical Parameter
|
Control System |
Siemens |
|
Packaging Type |
Carton |
|
Applicable Containers |
PET bottle, HDPE bottle, PE bottle, tin can, glass bottle |
|
Capacity |
Finish 3 cartons each time：500~600 ctn/h |
|
Packing Formats |
? Rows *? Columns =1 Carton (customized according to customer's packing formats) |
|
Weight |
2500kg |
|
Power |
3.5KW |
Main Features
01
The main drive adopts variable frequency speed regulation and PLC control technology, combined with human-machine interface, to achieve stepless speed regulation. The main control adopts a German SIEMENS programmable controller.
02
This machine is equipped with special pneumatic components in conjunction with a grabbing head to achieve the grabbing and releasing of products. Through mechanical operation, pneumatic and electrical control, the product is accurately loaded into the carton from the bottle conveyor, ensuring smooth operation.
03
The entire packing process is driven by a servo motor to independently drive different mechanical mechanisms to lift, translate, and lower the product, and is combined with pneumatic, electrical, and optical control to achieve automated operation. Coordinated movements, smooth and accurate movements.
04
The transmission channel adopts a pressure free control design.
05
Comply with food hygiene requirements: use oil-free lubricated pneumatic components.
06
The carton entry operation is equipped with manual entry, automatic entry, and continuous fast entry methods.
07
The head grabbing operation is equipped with manual and automatic operation.
08
Equipped with multiple protection functions, it can shut off in time in case of faults.It automatically stops and waits when the cartons are not fully loaded; It automatically stops and waits when there are not enough bottles on the bottle conveyor.
Main Configuration
|
PLC |
Siemens (Germany) |
|
|
Gearbox Motor |
JMC （China) |
|
|
Linear Guide Rail |
IGUS（Germany） |
|
|
Photoelectric Switch |
Omron（Japan） |
|
|
Low Voltage Electrical Components |
Schneider（France） |
|
|
Frequency Converter |
Delta （Taiwan） |
|
|
Pneumatic Components |
AirTAC（Taiwan) |
|
