HBM Load Cell Based Linear Weighing Type Filling Machine

The machine mainly adopts 304 stainless steel as materials so it is durable and stable quality. The appearance adopts a combination of stainless steel and tempered glass, which is convenient for maintenance and has a certain degree of dust prevention function. With PLC control system, the filling process is monitored in real time. Adopting the most advanced weighing measurement technology in the industry, the accuracy of the filling machine is not affected by the temperature and density of the oil. No need for repeated calibration.

Inquiry

Write a Review

Product Model

Model	JX-02CZA	JX-04CZA	JX-06CZA	JX-08CZA	JX-10CZA	JX-12CZA
Filling Nozzles	2	4	6	8	10	12
Capacity (Based on 1L)	350-500BPH	700-900BPH	1000-1200BPH	1200-1500BPH	1500-1800BPH	1800-2200BPH
Capacity (Based on 5L)	350-420BPH	700-840BPH	1000-1100BPH	1200-1400BPH	1500-1650BPH	1700-2000BPH
Filling Range	1L~5L	1L~5L	1L~5L	1L~5L	1L~5L	1L~5L
Filling Accuracy	±2g	±2g	±2g	±2g	±2g	±2g
Model	JX-02CZB	JX-04CZB	JX-06CZB	JX-08CZB	JX-10CZB	JX-12CZB
Filling Nozzles	2	4	6	8	10	12
Capacity (Based on 5L)	350-420BPH	700-840BPH	1000-1100BPH	1200-1400BPH	1500-1650BPH	1700-2000BPH
Capacity (Based on 20L)	200-250BPH	400-450BPH	550-650BPH	700-850BPH	900-1000BPH	1000-1200BPH
Filling Range	5L~25L	5L~25L	5L~25L	5L~25L	5L~25L	5L~25L
Filling Accuracy (Based on 5L)	±2g	±2g	±2g	±2g	±2g	±2g
Model	JX-02CZC	JX-04CZC	JX-06CZC	JX-08CZC	JX-10CZC	JX-12CZC
Filling Nozzles	2	4	6	8	10	12
Capacity (Based on 1L)	350-500BPH	700-900BPH	1000-1200BPH	1200-1500BPH	1500-1800BPH	1800-2200BPH
Filling Range	0.1L~2.5L	0.1L~2.5L	0.1L~2.5L	0.1L~2.5L	0.1L~2.5L	0.1L~2.5L
Filling Accuracy	±2g	±2g	±2g	±2g	±2g	±2g
Model	JX-02CZD	JX-04CZD	JX-06CZD	JX-08CZD	JX-10CZD	JX-12CZD
Filling Nozzles	2	4	6	8	10	12
Capacity (Based on 5L)	350-420BPH	700-840BPH	1000-1100BPH	1200-1400BPH	1500-1650BPH	1700-2000BPH
Capacity (Based on 20L)	200-250BPH	400-450BPH	550-650BPH	700-850BPH	900-1000BPH	1000-1200BPH
Filling Range	1L~25L	1L~25L	1L~25L	1L~25L	1L~25L	1L~25L
Filling Accuracy (Based on 5L)	±2g	±2g	±2g	±2g	±2g	±2g
Applicable Containers	PET bottle, HDPE bottle, PE bottle, tin can, glass bottle
Applicable Liquids	edible oil, lubricant oil, engine oil
Power	3KW	4KW	5KW	6KW	7KW	8KW
Air Pressure	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa	0.6~0.8Mpa
Size	The actual size is customized according to the customer's sample containers and subject to the actual product.

Model	JX-02CZR	JX-04CZR	/	/	/	/
Filling Nozzles	2	4	/	/	/	/
Capacity (Based on 20L)	200-250BPH	300-450BPH	/	/	/	/
Filling Range	15L~25L	15L~25L	/	/	/	/
Filling Accuracy (Based on 20L)	±5g	±5g
Applicable Containers	Flexible packaging bags
Applicable Liquids	edible oil, lubricant oil, engine oil
Power	3KW	4KW	/	/	/	/
Air Pressure	0.6~0.8Mpa	0.6~0.8Mpa	/	/	/	/
Size	The actual size is customized according to the customer's sample containers and subject to the actual product.

Technical Parameter

Measurement Mode	HBM load cell
Conversion Adjustment	Data storage and recovery system
Control System	Siemens
Drip-proof System	Vacuum resorption drip-proof system
Fault Alarm	Three-color alarm light+buzzing alarm sound
Speed Level	Fast --slow
Lifting Method	Electric lifting
Appearance	Stainless steel + tempering glass door (Dust free filling)
Oil Storage Tank and Liquid Material Pipeline	Stainless steel
High Level Tank	Liquid level control
Pipeline Pump	Built-in pipeline connection

Main Features

HBM Load Cell Based Linear Weighing Type Filling Machine 14

The machine mainly adopts 304 stainless steel material so it is durable and stable quality.

HBM Load Cell Based Linear Weighing Type Filling Machine 15

The appearance adopts a combination of stainless steel and tempered glass, which is convenient for maintenance and has a certain degree of dust prevention function.

HBM Load Cell Based Linear Weighing Type Filling Machine 16

With a PLC control system, the filling process is monitored in real time.

HBM Load Cell Based Linear Weighing Type Filling Machine 17

Adopting the most advanced weighing measurement technology in the industry, the accuracy of the filling machine is not affected by the temperature and density of the oil. No need for repeated calibration.

Filling nozzles adopt lifting devices and vacuum resorption systems so that they are anti-dripping. And each filling nozzle can be individually shielded without affecting the use of other filling nozzles.

The filling speed is adjusted automatically by the independent weighing units on each filling nozzle.

Due to the liquid level control inside the high-level tank, it ensures more stability of oil pressure and filling accuracy.

The internal oil pipeline adopts 304 stainless steel round pipes and 304 stainless steel corrugated pipes to eliminate plasticizers and ensure oil safety.

Intelligent human-computer interaction, convenient and flexible operation. The data storage system can store and remember multiple filling range parameters, making it convenient and fast to switch filling ranges.

Main Configuration

Load Cell	HBM (Germany)
PLC	Siemens (Germany)
Touch Screen	MCGS
Solenoid Valve	SMC (Japan)
Cylinder	AirTAC (Taiwan)
Gas Source Triplet	AirTAC (Taiwan)
Photoelectric Switch	Omron (Japan)
Vacuum Generator	SMC (Japan)
Contactor	Schneider (France)
Thermal Relay	Schneider (France)
Switch Power Supply	MEAN WELL (Taiwan)
Leakage Switch	Schneider (France)
Unipolar Air Switch	Schneider (France)
Photoelectric Switch	Omron (Japan)
